Application of Product........

BREATHING AIR COMPRESSOR SYSTEMS

High Pressure Breathing air Compressor systems that are characterized by innovative technical solutions and quality.

PURIFIER CARTRIDGES

Purifier cartridges have been developed indigenously and approved by Defence Ministry which give the Quality of Air conforming to International standard BS 4275.

SPARE PARTS AVAILABILITY

Fast moving spare parts are kept in stock for supply at short notice, to minimise down time of compressors in use with the customer.

These compressors are used in:
	• Hospitals • Shipyards • Large workshops • Industrial use	• Fire Services • Mines • Underwater Diving	• Aircraft Engines • Auto Industries • Oil Exploration

Manufacturer of:

• Portable Water mist Fire Fighting System, most suitable for approaching buildings situated in narrow lanes where vehicles approach is difficult;

• Air Purifier Filter Cartridges for all models of High Pressure air Compressors. These Cartridges are tested and approved by highly rated Defence Laboratory in Mumbai (India).

Technical Specifications :

GA-3

Charging Rate / Capacity	100 Ltr/Minute (3.5Cfm/6 Cum/Hr)
Max. Pressure	300 Bar
Working Pressure	200-300 Bar
Intake Pressure	(Atmospheric)
Intake Temperature	5 Deg.C. To 40 Deg. C.
Final Temperature	5 Deg.C to 45 Deg.C
Cooling	Air Cooled/Intercooler/After cooler Provided
Intake State	Air Intake Filter Is Provided
Quality Of Outlet Air	BS4001/DIN 3188/EN12021
No. Of Outlets	01 or 2
No. Of Stages	03
Safety Valves After each stage of Compression	By Controlled Splash Lubrication
Motor Required	3 HP/2.2 KW
Weight	Not More Than 60 Kg.
Prime Mover-Electric motor	3 ph. 415V 50HZ or Single Phase, 220 Volts
Diesel Engine	Suitable
Petrol Engine	Suitable
Pressure Gauge	Provided for final stage.
Speed	2200 RPM max.

The compact dimensions of three stage Air cooled Compressor are light weight (approx..60 kgs).
Driven with electric motor single phase 220 volt/414 volt 3 phase 50 cycles, Motor 2.5 kw/petrol driven.
It is easy to transport and extremely reliable unit and is ideal for filling cylinders, water sports, fire fighting, medical services besides other uses.

GA-6

Charging Rate/Capacity

140-195 Ltr/Minutes (5-7cfm minute)

Working Pressure

350 Bar

Max. Pressure

330 Bar

Intake Temperature

5 Deg. C to 45 Deg. C

Final Temperature

Not more than 15 Deg.C of inlet temperature

Cooling

Air Cooled/Intercooler/Aftercooler Provided

Intake State

Air Intake Filter Is Provided

Quality Of Outlet Air

Conforming to BS 4275/BS4001/EN12021

No. Of Outlets

No. Of Stages

Safety valves after each state of compression

By Controlled splash

Weight

Not more than 150 kgs.

Motor Required

5 Hp

Prime Mover-Electric motor

3 ph. Squirrel cage, 414V 50 HZ

Diesel Engine of Greaves Model 1080 as per requirement of customer.

GA-9

Capacity	250 LPM
Operating pressure	200 & 300 BAR
Maximum working pressure	330 BAR
Intake Pressure	1/103 BAR
Intake Temperature	5 Deg.C. To 50 Deg. C.
Final Temperature	Not more than 20 Deg.C of inlet temperature
Cooling	Air Cooled
Intake State	Air intake filter with suitable suction filter.
Quality Of Outlet Air	As per international Standard EN 12021/DIN3188
No. Of Stage	3 (Three)
Filling hose	Two (2) hoses with suitable adopters.
Noise level	Noise level < 85 db at 1 meter distance.
Control Panel	Start & Stop Switches, Emergency Stop Switch, Amp., Volt, Hr Mtr, Indicating Light,
Mehanical panel	Pressure gauge 1st stage, Iind stage & final stage.
Safety valve	Safety valve at each stage.
Pressure switch	To set filling pressure & for Automatic Stop so that Compressor stops when cylinder filled to desired pressure.
Automatic drain	Manual & Automatic drain will be provided.
Low oil protection	Low oil protection to indicate if Oil Level in Compressor is Low. Compressor should shut down / not start if Oil level is low.
Trolley	Common base frame with Trolly mounted lock wheel.
Compressor system	The Compressor will be a multi stage Air cooled High Pressure Compressor with inter cooler between stages and after cooler after final stage, safety valve etc. The air should be sucked in via a suction filter to remove dust particles in air and then it should be compressed in the Compressor. After compression the moisture should be separated and air should be filtered in the main filter cartridge to remove all impurities to make it suitable for breathing.
Prime Mover	Suitable 7.5 H.P. 3 Phase Electric Motor, 415 V, 50Hz, 2880 RPM of reputed make
Weight of the equipment	<180 Kg.

Portable 3 stage Air cooled compressor designed to operate at maxmium working pressure 330 Bar and the charging rate of 140 lit/min. to 160 lit./min driven with 3 phase electric motor 414 volts 3 phase / diesel engine Greaves 1510 suitable for heavy duty service, Intercoller / after cooler provided safety valves at each stage.
Model is particularly suitable for long term operations in hospitals, mines, rescue works, Naval Dockyards under water diving duty etc.
